Dedicated to Provision of Long Term Stable Running IoT Devices
5 Years
| Ask Lasest Price | |
| Certification : | ce, FCC, UL, RoHS, Weee, GS, BQB, BIS（ISI） |
| Brand Name : | iStartek |
| Model Number : | VT600 |
| Supply Ability : | 9000000 Piece/Pieces per Month |
| Price : | $10.00 - $26.00 / Piece |
| Vehicle GPS Tracker For Fleet Management | |
| VT600 | ||
VT600 is a GPS/GPRS based tracking device, specially developed and designed for vehicle real-time tracking and fleet management. VT600 has an inbuilt GPS module to obtain accurate position data. This device utilizes its GSM capability to send position data to a specified mobile phone or server base for tracking and fleet management. With internal memory, VT600 can store GPS coordinates when there is no GPRS connection, or at a specified interval requested by the user. One optional feature of VT600 is that a microphone can be linked and hidden somewhere inside the vehicle for listening to the cabin. |
| Feature |
 | Remote Cut-off (petrol/power) Compel the vehicle to stop by breaking off the fuel connection |  | Anti-Jammer (optional) Resist GPS or GSM jammer to keep working and report to GPS tracking software | |||
 | 1-Wire Interface 1-wire interface for temperature sensor/ ibutton (customized version) |  | Listen-in Allows the caller to listen to what is happening around the tracker | |||
 | 4MB Flash Memory Store GPS coordinates when there is no GPRS connection, or at a specified interval requested |  | Smart Alarms Movement alarm, low battery alarm, GPS blind area alarm, power-cut alarm, GPS antenna disconnect alarm and Geo-fencing alarm | |||
 | Multiple I/O Interfaces Monitor and control external application via input/outputs |  | Tracked by: SMS, APP, Web Reporting location in real time through different interfaces |
| Interface |
| Application |
| Specification: |
Items | Specifications |
Power Supply | 10.6V - 36V / 1.5A |
Backup Battery | 500mAh |
Normal power consumption | 55mA/h |
Dimension | 65mm x 61mm x 26mm |
Weight | 90g |
Work time | 30 hours in power-saving mode and 7.5 hours in normal mode |
Operating temperature | -20° to 65° C |
Humidity | 5% to 95% Non-condensing |
GPS Module | latest GPS SIRF-Star IV chipset |
GPS Sensitivity | -159Db |
GPS Frequency | L1, 1575.42 MHz |
C/A Code | 1.023 MHz chip rate |
Channels | 20 channel all-in-view tracking |
Position Accuracy | 10 meters, 2D RMS |
Velocity Accuracy | 0.1 m/s |
Time Accuracy | 1 us synchronized to GPS time |
Default datum | WGS-84 |
Reacquisition | 0.1 sec., average |
Hot start | 1 sec., average |
Warm start | 38 sec., average |
Cold start | 42 sec., average |
Altitude Limit | 18,000 meters (60,000 feet) max |
Velocity Limit | 515 meters/second (1000 knots) max |
LED | 2 LED lights to show GPS/GSM status |
Flash Memory | 4MB |
Button | One SOS Button |
Interface | 3 digital inputs (1 negative, 1 positive triggering and 1 input changeable) 1 analog input 1 output. |
| Standard Accessories: |
Standard Accessories:
| VT600 Tracker | GSM Antenna | GPS Antena | Power Cable |
Free GPS Tracking System: |
We provide free GPS Tracking System for one year, simple and easy for management and tracking!
Features | Descriptions |
Time Zone & Local Language | More than 10 languages and timezone settings |
Multiple Account Support | Allow you to set up an account for company user to management many vehicles |
Group Management | The user can manage the vehicle by setup difference groups |
Reporting and Export | The overview report, Speeding report, Mileage report, Stop Report |
Real-Time Tracking | Track the vehicle by real-time |
Location History | Replay the location history |
SOS Alarm | SOS Alert |
Communication Failure Monitoring | Monitor the vehicle when it is not reporting |
Over Speed Monitoring | Monitor the vehicle when it is over a speed |
Online Vehicle Engine Control | Turn on or turn off the engine |
Geo-fence Notification | Set up a zone to monitor the vehicle enter or exit this zone. |
Landmark | Mark the new point in the map by yourself |
OEM & ODM Case Study: |
Case 1: customized vehicle tracker to meet Chile bus group's request and installed more than 2000pcs already.
Case 2: As per Indian's Telecom Provider's request, we customized portable tracker to track GSM station's Backup batteries, for an anti-theft purpose.
Case 3: Customized VT600 2G GPS Tracker as per Thailand DLT request, connecting with Magnetic Card Reader to collect driver's ID card data, controlling car engine by card swiping.
| Package and Delivery: |
Package:
1. VT600 Size: 65*61*26mm
2. VT600 Weight: 105g
3. VT600 will be packed by gift box, the size is 133*103*72mm, 350g per ft box
Delivery:
1. Sample and mini order will be delivered within 2-3 working days after the receipt of payment.
2. For order over 500pcs or customized order, lead time will be 3-5weeks after the receipt of payment.
FAQ: |
1. Are you a manufacturer?
|
|
