Dedicated to Provision of Long Term Stable Running IoT Devices
5 Years
| Ask Lasest Price | |
| Certification : | CE, ROHS, ISO9001, Patent |
| Brand Name : | iStartek |
| Supply Ability : | 999999 Piece/Pieces per Month |
| Price : | $1.00 - $19.00 / Piece |
| Model Number : | MC119 4G Wireless Router |
| Payment Terms : | L/C, D/A, D/P, T/T, Western Union, MoneyGram, Paypal |
| Delivery Time : | 1-7 days |
| PRODUCT OVERVIEW |
| iStartek Wireless Router MC119 with RJ11 RJ45 Port | |
| 4G Home Wifi Router (CPE) | ||
MC119 RJ11 4G LTE WiFi Router is 2.4GHz, 802.11 a/b/g/n. It has lots of Multifunctional Interface:2 RJ11 4RJ45 port, 1USB port. It Supports 2 External Antennas. MC119 will also be able to connect to other WIFI devices while launching WIFI, such as monitoring camera, computer, and cash devices. Such as WIFI Hotspot in the Office, Home Gateway and Voice Calls, Outdoor Network Connection, Monitor and Other WIFI Devices, Areas without Wired Network Access and Party Outside. |
| WHY CHOOSE OUR MC118? |
1. Support 2G/3G/4G network, LTE bands can be customized.
2. Qualcomm MDM9207+QCA6174 chipset.
3. Support VoLTE/VOIP/CS Domain voice with RJ11 port.
4. 4X 10/100/1000Base Ethernet port.
5. Support IEEE 802.11 a/b/g/n standard ,WiFi rate up to 750Mbps.
6. Support web management.
7. Support network data traffic statistics.
8. Support more than 32 WIFI devices online simultaneously.
| SPECIFICATIONS |
Technical | Specifications |
4G Platform | Qualcomm MDM9207 |
Modem | LTE-FDD/TDD-LTE/WCDMA |
LTE | FDD: B1/B3/B5/B7/B8/B28 TDD: B40 Other frequencies need to be customized |
3G/2G | WCDMA: B1/B5/B8 GSM: B2/B3/B5/B8 |
Rate level | CAT4 DL:150Mbps / UL:50Mbps |
Transmitting power | 23dBm |
Antenna | External antenna and internal antenna, Gain>3db |
WIFI | |
WIFI Band | 2.4/5GHz,802.11a/b/g/n/ac |
WIFI Rate | Highest rate 750Mbps |
WIFI Standard | IEEE 802.11a/b/g/n/ac |
Number of linking users | Maximum 32 users connected |
| FAQ |
1. How to restore factory settings?
When the router is power on, click the reset button for
approximately 3 seconds using a pointed object until the indicator
starts to blink. Restoring factory settings will clear all
customized settings.
2. How can I connect to the router by the Wi-Fi Protected Setup(WPS) function?
1. Ensure that WiFi is enabled on the client.
2. Press the WPS button on the router to set up a WPS connection
3. How to deal with the contents displayed issue of the WebUI
Manually clear your browser’s cache (for example, open your browser
and choose Internet Options > General >
Browsing history > Delete.) and re-launch the WebUI page.
4. Why the router does not work after I have finished configuring?
1. Ensure that you have a working standard Sim card inserted
properly.
2. Move the router to an open space free from obstructions and make
sure there are available mobile networks.
3. If the problem persists, please contact your network service
provider.
5. Why the Internet status indicator is persisting on, but the WiFi
indicator is off?
Your mobile network may have a poor signal. Try to move the router
to a place with better reception. An External
an outside antenna may be required to increase the network signal
strength.
6. Why can’t I access the router’s WebUI?
1. Ensure that your computer is connected to the router through
WiFi or the Ethernet cable.
2. Ensure that your computer is set to obtain an IP address and DNS
server address automatically.
3. Restart your browser or try using another browser.
4. If the problem persists, restore the router to factory settings
and try to access WebUI again
|
|
