Dedicated to Provision of Long Term Stable Running IoT Devices
5 Years
| Ask Lasest Price | |
| Brand Name : | iStartek |
| Model Number : | PT55 Asset GPS Tracker |
| Certification : | CE FCC ROHS NBTC |
| Price : | $1.00-$27.00/PC |
| Payment Terms : | L/C, D/A, D/P, T/T, Western Union, MoneyGram, Paypal |
| Supply Ability : | 900000 Piece/Pieces per Month |
| Delivery Time : | 1-7 days |
Long stand by device low power consumption to 2µA when standby locate one times a day can lifelong for three years <over than 1200 pcs data> small and smart mainly using in financial rental and private car areas.
| Item | Specifications |
| Working voltage | DC 3V |
| Working current | 60-80mA @3V |
| Standby current | <3.5uA |
| Size | L77mm*W41mm*H27mm |
| Location Way | GPS |
| Location Accuracy | <10 meter |
| Communication Network | GPRS GSM:800/900/1800/1900 MHz Quad-band |
| Communication way | UDP |
| Working temperature | -25℃+75℃ |
| Storage temperature | -40℃+85℃ |
| weight | 100g |
| Battery life | 3 years (CR123A) |
Function:
Alarm Mode | Can set wake-up time 4 times each day, would wake-up automatically in the set time and after sending the Data then go into sleeping mode |
Timer Mode | Sent the data at one fixed time and sent the location data in the setting time |
Week Mode | Can set a time point and one day or several days in one week to send the data and then go into sleeping mode |
LBS tracking+ GPS tracking | When GPS cannot get the signal, the LBS tracking would start working automatically |
Serial port set-up | Can set IP and port, APN, Equipment number, correct time, alarm mode, timer mode, week mode |
Message set-up | Can set IP and port, APN, Equipment number, alarm mode R, timer mode. W, week mode |
Message inquiry | Return back to reference setting |
Message to the correct time | Use the mobile edit (C: TIME) send to the terminal equipment, after the terminal gets the message and would apply time correct to the platform automatically. |
Tamper alarm | When the equipment detected the light turn to bright, the equipment will send an alarm message to the platform. |
Anti-fake-LBS location | Then the device will refuse to connect to the fake-LBS locate when detected |
Application:
We provide a free GPS Tracking System for one year, simple and easy for management and tracking!
Features | Descriptions |
Time Zone & Local Language | More than 10 languages and timezone settings |
Multiple Account Support | Allow you to set up an account for company user to management many vehicles |
Group Management | The user can manage the vehicle by setup difference groups |
Reporting and Export | The overview report, Speeding report, Mileage Report, Stop Report |
Real-Time Tracking | Track the vehicle by real-time |
Location History | Replay the location history |
SOS Alarm | SOS Alert |
Communication Failure Monitoring | Monitor the vehicle when it is not reporting |
Over Speed Monitoring | Monitor the vehicle when it is over a speed |
Online Vehicle Engine Control | Turn on or turn off the engine |
Geo-fence Notification | Set up a zone to monitor the vehicle to enter or exit this zone. |
Landmark | Mark the new point in the map by yourself |
